Professional Suction Feed Spray Gun | ASG3101 | 1000cc High-Capacity Base Coat Gun
|
Specification |
Details |
|
Model Number |
ASG3101 |
|
Nozzle Size (Standard) |
1.5mm |
|
Paint Capacity |
1000cc (1.0 Liter) |
|
Feed Type |
Suction Feed |
|
Pattern Width |
140mm – 180mm |
|
Operating Pressure |
3.0 – 4.0 Bar (43.5 – 58 PSI) |
|
Air Consumption |
4.2 – 7.1 cfm (119 – 200 l/min) |
|
Connectors Included |
Europe, USA, Nitto, and Italy Types |
|
Optional Nozzle Range |
1.2mm – 1.8mm |
|
Application |
Base Coats / Primers |
- High-Capacity 1000cc Reservoir: The oversized suction cup allows for prolonged spraying sessions on large vehicles or industrial structures without constant stopping for refills.
- Optimized for Base Coats: The 1.5mm nozzle is precision-machined to handle the viscosity of base coats and primers, ensuring an even and reliable foundation for finishing layers.
- Universal Fitting System: Supplied with Europe, USA, Nitto, and Italy type connectors, guaranteeing a leak-free connection to any standard workshop air line.
- Durable Suction Feed Design: The bottom-mounted cup design is ideal for spraying at various angles and provides excellent balance for larger volume applications.
- Consistent Spray Performance: Operating at a pressure of 3-4 bar, this gun maintains a stable 140-180mm pattern width for uniform coverage and reduced overspray.
