EZVIZ HP7 Wired Video Door Intercom System - 3MP Outdoor Panel, 7" Touch Screen, RFID & Remote Unlock (CS-HP7-R101-1W2TFC)
|
Specification Category |
Outdoor Panel |
Indoor Display |
|
Model |
CS-HP7-R101-1W2TFC |
(Part of Kit) |
|
Resolution |
2048 × 1296 (3MP) |
1024 × 600 |
|
Lens/Screen Size |
2.0 mm, 162° Diagonal View |
7” touch screen |
|
Video Compression |
H.265 / H.264 |
N/A |
|
Connection Type |
Wired (2-Wired/4-Wired) |
Wi-Fi (Dual-Band 2.4/5G) |
|
Access Control |
RFID badge unlock (3 badges) |
Indoor display unlock, App remote unlock |
|
Gate/Lock Output |
Dry Contact (12V/2A Gate), Wet Contact (12V/1.1A Lock) |
Controls Gate/Lock via Terminal |
|
Smart Alarm |
Human Motion, Lingering Detection, Tamper Alarm |
N/A |
|
Local Storage |
N/A |
Supports microSD card (Max. 512 GB) |
|
IP Grade |
Waterproof, with shield cover |
N/A |
|
Operating Temp. |
-30°C to 60°C |
-10°C to 45°C |
|
Audio |
Built-in high-sensitivity microphone/speaker |
|
|
Camera Tech |
Supports low light sensitivity (CMOS Sensor) |
|
|
Installation |
Includes Wall Bracket, Drill Template, Screw Kit |
|
|
Notifications |
Mobile App Alerts (Inferred) |
|
|
Customization |
Up to 20 Ringtones (Confirmed) |
|
-
High-Resolution 3MP Video: The outdoor doorbell features a wide-angle 162° (Diagonal) lens and 2048 × 1296 Max. Resolution (3MP) for clear, detailed viewing of visitors, day or night (with 6m IR distance).
-
7-Inch Indoor Touch Display: Includes a central 7" touch screen (1024 × 600 resolution) for viewing live footage, initiating two-way talk, and unlocking the door/gate directly.
-
Triple Door Access Methods: Supports highly flexible access control with RFID badge unlock (3 included badges), convenient App remote unlock, and direct Indoor display unlock.
-
Reliable Wired Connection: Uses a Wired connection (2-Wired/4-Wired capable) for stable digital signal transmission up to 120m (Twisted Pair), ensuring consistent performance without Wi-Fi dropouts.
-
Smart Security & Intercom: Features Smart Human Motion Detection and Lingering Detection on the outdoor panel, coupled with Long-distance video two-way talk for secure, clear communication.
